Hydraulic Tools
AFHC-E
Hydraulic Cutter
Specialized for round bar, steel plate and cable.
Hydraulic Cutter connects to a hydraulic motor pump or a hydraulic hand pump to cut. Core technology makes rescue cutter quicker, easier and safer.
✓
Two-way self-locking, auto-reset reversing hand valve✓
Tool body in aeronautical aluminium, ceramicized surface✓
Central bolt structure for tight spaces✓
Imported seals and alloy steel bladesTechnical Specifications
Working pressure
72 MPa / 720 bar
Max. opening distance
105 mm
Max. cutting capacity
ø25 mm (round bar)
Weight
14.5 kg
Operating temperature
-30°C to +55°C
Dimensions
845 × 255 × 185 mm
Applications
Fire & Rescue
Earthquake response
Structural collapse
